ETERNA CW Sewage De-watering Submersible Pumps

TECHNICAL SPECIFICATION

• Head Range : Upto 70 Metres
• Discharge Range : Upto 4800 LPM
• Power Rating : 0.75 to 15 kW (1 to 20 HP)
• Voltage Range : 380 to 440 Volts (Three phase.)
• pH Value : 6.5 to 7.5
• 3 Maximum Density : < 1050 kg/m
• Protection : IP 68
• 3 3 Consistency of Medium : < 1.2 x 10 kg/m
• Maximum Ambient Temperature: 40 °C
• Insulation : “B”/ “E”Class

MATERIAL OF CONSTRUCTION

• Impeller : Cast Iron
• Delivery Casing : Cast Iron
• Motor Body : Cast Iron
• Pump Shaft : Carbon Steel

APPLICATIONS

• Sewage pumping
• Dewatering from basements, multi-storeys, shopping malls, godowns
• Construction site
• Dewatering foundation, trenches and pits
• Flood water handling

FEATURES

High Efficiency and Energy Saving Design lnnovative design manufactured at state of art plant, delivers optimum efficiency at lower energy consumption resulting in significant cost savings.

Easy Maintainable Designs

Easy maintainable design and better interchangeability of components so that pump can be serviced even at remote locations by semi-skilled technicians.

Robust Construction

Heavy duty construction made from graded cast iron, carbon + silicon carbide mechanical seal makes the pump suitable for sewage and sludge.

Replaceable Wearing Parts

All wearing parts within the pumps are easily accessible and replaceable which facilitates ease of maintenance thereby extending the life of the pump.

Dynamically Balanced Rotating Parts

Minimum vibrations protect components from damages during the operations, thus ensuring consistent performance as concentricity is maintained
